KHCV Weldable Strain Gauge

Measurement Environment: Dynamic 800ºC
Applications: Uniaxial, 1-element active

Typical Applications for Grasping the physical properties of:

• High-temperature gas turbine blades
• Aircraft jet engine turbines
• Incinerators and heat treat furnaces
• Petrochemical reactors
• Heat-resistant alloys, etc

With the KHCV, gauge factor is improved by approximately 50% over our forerunner previous model. This is realized through improvement of the spot-welding method and adoption of a low-resistance Ml cable. Also realized is the 120 Q gage resistance in 5 mm gauge length.
